Model |
MS12 |
|
Weight |
1200kg |
|
Digging bucket capacity |
0.025cbm/120kg |
|
Bucket width |
380mm |
|
Engine |
Kubota D722 |
|
Bore stroke |
Three cylinders,water cool |
|
Rated power |
10.2kw/2500r/min |
|
Displacement |
6.8mlr |
|
Main pump |
G5-6 |
|
Swing motor |
China brand |
|
Travelling motor |
China brand
USA EATON motor(optional)
|
|
Travel speed |
1.5kmh |
|
Battery |
12V 60A |
|
Main Demensions |
|
|
Overall dimension( LxWxH) |
2770x896x1490 mm |
|
Wheelbase |
910 mm |
|
Total length of track |
1230mm |
|
Plattorm ground clearance |
380 mm |
|
Platform back tuming radius |
784 mm |
|
Chassis width |
896 mm |
|
Track width |
180 mm |
|
Chassls ground clearance |
132 mm |
|
Track height |
320 mm |
|
Operating Range |
|
|
Max Digging depith |
1650 mm |
|
Max. Vertical dgging depth |
1375 mm |
|
Max Digging height |
2610 mm |
|
Max. Dumping height |
1850 mm |
|
Max, Digging radius on ground |
2850 mm |
|
Min. Rotation radius |
1330 mm |
|
Max. Upgrade helght of bulldozer blade |
345 mm |
|
Max. Digging depth of bulozer blade |
255 mm |
|
|
|
|
|
