Operating load (kg) |
850 |
|
Max Speed（km/h） |
12 |
|
Rated flux (L/min) |
75 |
|
High Flow Flux (L/min) |
/ |
|
Tire（track） model |
12-16.5 |
|
Rated power (Kw) |
45 |
|
Fuel tank capacity (L) |
80 |
|
self weight bucket (kg) |
2800 |
|
Bucket capacity (m³) |
0.4 |
|
Overall operating height (mm) |
4000 |
|
Height to bucket hinge pin (mm) |
3100 |
|
Hheight to top of cab (mm) |
2160 |
|
Height to bottom of level bucket(mm) |
2933 |
|
Without bucket length（mm） |
2750 |
|
Overall length with bucket(mm) |
3490 |
|
Dumping angle at maximum height(° ) |
40 |
|
Dumping height(mm) |
2400 |
|
Dumping reach(mm) |
750 |
|
Rollback o bucket on ground(° ) |
30 |
|
Rollback of bucket at full height(° ) |
104 |
|
Wheelbase(mm) |
991 |
|
Ground clearance(mm) |
205 |
|
Angle of departure(° ) |
20 |
|
Front turning radius without bucket(mm) |
1198 |
|
Front tuning radius(mm) |
1958 |
|
Rear tuning radius(mm) |
1728 |
|
Rear axle to bumper (mm) |
1208 |
|
Tread width (mm) |
1500 |
|
Width (mm) |
1880 |
|
Bucket width (mm) |
1880 |
|
|
|
